FP Sync FrSky TWIN X14 Custom Preloaded Package

FP Sync FrSky TWIN X14 Custom Preloaded Package

The FP Sync TWIN X14 Package gives you a professionally programmed FrSky radio system built around the aircraft you actually fly. Choose your transmitter color, select between 1 and 10 TW GR8 receivers, and choose one custom aircraft profile for each receiver.

Every selected model profile is loaded onto the radio, each receiver is bound to the transmitter, and the applicable controls, telemetry, voice alerts, rates, flight modes, flaps, retracts, reverse thrust, and stabilizer functions are configured before shipment.

Build Your FP Sync Package

1. Choose a Black or White TWIN X14 transmitter.
2. Select between 1 and 10 FrSky TW GR8 receivers.
3. Choose one aircraft profile for each receiver.
4. Tell us whether a non-factory-equipped aircraft uses no stabilizer or an add-on FMS Reflex V3.
5. Add any special installation or programming information in the notes field.

Each receiver is matched with its corresponding aircraft profile. For example, a two-receiver package can be configured for an FMS 1300mm PA-18 and an Arrows 1300mm Bigfoot, giving you two bound receivers and two ready-to-use model profiles on the same transmitter.

What’s Included

• FrSky TWIN X14 transmitter in your selected color
• Your selected quantity of FrSky TW GR8 receivers
• One professionally programmed aircraft profile per receiver
• Each TW GR8 receiver registered and bound to the transmitter
• Flight Pro Master Model File for future aircraft setups
• Rechargeable FrSky 2S transmitter battery
• FrSky transmitter carrying case
• Flight Pro quick-start and setup guidance

Aircraft, flight batteries, servos, ESCs, and stabilizer hardware are not included.

Professional Aircraft-Specific Programming

This is more than a transmitter and receiver bundle. Each profile is built around the functions and equipment commonly found in the selected aircraft.

Depending on the aircraft and its installed equipment, programming may include:

• Aileron, elevator, rudder, and throttle channel assignments
• Throttle-cut safety control
• Dual rates and aircraft-appropriate control settings
• Flap control and flap-position voice callouts
• Independent elevator trim for configured flap flight modes
• Retract and landing-gear control
• Reverse-thrust control where supported
• FMS Reflex or Arrows Vector mode control where applicable
• Panic or auto-level recovery control where supported
• Receiver voltage and RF-link telemetry
• Altitude and vertical-speed telemetry from the TW GR8 variometer
• Flight-battery voltage monitoring when the required telemetry connection is installed
• Low-voltage and critical-voltage voice alerts
• Flight timer and motor timer configuration
• Aircraft-specific switch assignments and voice feedback
• Flight Pro ETHOS display and model organization

Available features vary by aircraft, installed electronics, and telemetry connections. Functions that are not supported by the selected aircraft will not be added simply to fill switches.

Factory Reflex and Vector Integration

Aircraft marked as Factory Reflex or Factory Vector are configured around the stabilizer system originally supplied with that model.

Where supported, the receiver can connect to the aircraft’s stabilizer through SBUS. This helps preserve the factory gyro functions while allowing the TWIN X14 to provide improved switch control, telemetry, voice alerts, timers, and aircraft-specific programming.

If your aircraft’s electronics have been changed from the stock configuration, describe those changes in the programming notes so the setup can be reviewed before shipment.

Aircraft Without a Factory Stabilizer

For aircraft that did not originally include a stabilizer, choose one of the following:

• No Stabilizer: The profile will be configured for a conventional receiver and servo installation.
• Add-on FMS Reflex V3: The profile will be prepared for a separately purchased, customer-supplied Reflex V3.

If you are unsure which option applies, include the aircraft version and a description of the installed electronics in the programming notes.

Technical Details

FrSky TWIN X14 Transmitter

The TWIN X14 is a compact ETHOS transmitter with professional radio features and FrSky’s dual-active 2.4GHz TW protocol. Unlike a basic active-standby system, both 2.4GHz links operate simultaneously in TW mode.

• FrSky ETHOS operating system
• Dual-active 2.4GHz TW protocol
• TW, ACCESS, and ACCST D16 protocol support
• High-precision Hall-sensor gimbals
• Up to 24 channels
• Low-latency operation with full telemetry
• 2.95-inch 640 × 360 color TFT display
• Four front quick-mode buttons
• Two rear momentary buttons
• Accessible top switches and shoulder sliders
• Voice announcements and haptic vibration alerts
• USB Type-C charging and data connection
• Built-in 128MB flash storage and TF card expansion slot
• PARA wireless trainer system
• Lite external module bay
• Compact ergonomic chassis with rounded hand grips

TWIN X14 Specifications

• Dimensions: 192 × 193 × 72mm
• Weight: 610g excluding battery
• Operating system: ETHOS
• Internal RF module: TW-ISRM
• Channels: Up to 24
• Display: 2.95-inch, 640 × 360 color TFT
• Operating voltage: 6.5–8.4V using a 2S battery
• Typical operating current: 330mA at 7.4V
• Operating temperature: -10°C to 60°C
• Charging and data: USB Type-C
• RF compatibility: TW, ACCESS, and ACCST D16

FrSky TW GR8 Receiver

Every package includes the selected quantity of FrSky TW GR8 receivers. Each receiver is registered and bound to the transmitter before shipment.

The TW GR8 combines eight PWM outputs, SBUS connectivity, full telemetry, dual-active 2.4GHz reception, and a built-in high-precision variometer in a compact receiver.

• Simultaneous dual-active 2.4GHz TW operation
• Eight PWM channel outputs
• SBUS output with expanded channel support
• SBUS input for supported redundant receiver configurations
• FBUS and S.Port telemetry support
• Built-in high-precision variometer
• Live altitude and vertical-speed telemetry
• External voltage monitoring through AIN2
• Basic Black Box data recording
• 4ms race mode with telemetry
• Over-the-air firmware updates
• Long-range control capability, dependent on RF settings and conditions

TW GR8 Specifications

• Frequency: Dual 2.4GHz TW protocol
• Dimensions: 38.1 × 14.6 × 9.5mm
• Weight: 5g
• Operating voltage: 3.5–10V
• Operating current: 120mA at 5V
• PWM outputs: 8
• Altimeter range: -700m to 10,000m
• Altitude resolution: 0.1m
• Vertical-speed range: ±10m/s
• AIN2 voltage range: 0–36V
• Compatibility: FrSky TWIN radios and RF modules operating in TW mode

Flight Pro Master Model File

The transmitter also includes a Flight Pro Master Model File that can be cloned for future aircraft. This gives you a clean starting point with the primary Flight Pro controls, safety features, telemetry organization, and switch layout already established.

Installation and Required Preflight Checks

The transmitter programming and receiver binding are completed before shipment, but every aircraft installation is different. Final setup and safety verification remain the pilot’s responsibility.

Before flight, you must:

• Install the receiver and any customer-supplied stabilizer correctly
• Connect each servo, ESC, telemetry lead, and accessory to the correct port
• Verify aileron, elevator, rudder, throttle, flap, retract, and reverse-thrust directions
• Verify stabilizer correction direction on every axis
• Confirm control-surface neutral positions and mechanical linkage setup
• Confirm travel, rates, endpoints, and flap positions
• Verify throttle cut and failsafe operation
• Verify telemetry values and voltage-alert settings
• Complete a receiver range test
• Confirm the aircraft’s center of gravity
• Perform a complete preflight inspection before every flight

Profiles are developed around the normal stock configuration of the selected aircraft. Different servos, ESCs, control boards, wiring arrangements, firmware versions, or other modifications can require additional adjustments.

Flight Pro Setup and Support Videos

For installation guidance, model cloning, ETHOS operation, switch assignments, telemetry setup, and Flight Pro programming information, visit the:

Flight Pro RC YouTube Channel

The FP Sync Advantage

Every FP Sync package is individually reviewed, programmed, bound, and tested before shipment. Instead of receiving a blank radio and a box of unbound receivers, you receive an organized radio system built around your aircraft collection.

• No receiver binding from scratch
• No blank model profiles
• No channel mapping from zero
• No flap or reverse-thrust programming from scratch where applicable
• No telemetry and voice-alert setup from scratch
• No guessing which model profile belongs with each receiver

Professionally programmed. Aircraft-specific. Ready for final installation and verification.

Compatibility Notice

This package is built around the FrSky TWIN X14 transmitter and TW GR8 receivers operating in TW mode. Flight Pro reviews each selected aircraft before programming. If a selected aircraft, custom installation, or requested feature requires different receiver hardware or additional information, we will contact you before completing the order.
